PLE Head
고압 기어펌프 Pump Module > Gear Pump > ~18,000L/Hour- 제품설명
-
- PLE - low temperature booster
- 저온 사용 (최대 120 °C) - 고압 적용 가능 (최대 500 bar)
- Abrasive fluid를 취급할 수 있음
- Viscosity : 1,000 - 1 - 1,000,000 cp
- Capacity rage : 1 - 2,500 cc/rev
- Rotational speed : 10 - 120 rpm
- Max outlet pressure : 4,350psi (< 300 bar)
- Operating temperature : < 120 °C
- Maker : MVV /ITALY
- 연락처
-
경기본사 : 031-790-1907 (내선2)
대전지사 : 042-824-5167
- Designed to reduce the pulsation downstream extrusion equipment and to highly increase its efficiency
- Core tempered Martensitic Stainless steel body, Plates and Gears (58 HRC) : 기계적 마모에 잘 견디며 내화학성 우수
- Packing as standard, lip seals on demand
- 맞춤형 설계 솔루션
| Applications | Materials | Shaft seal | On demand |
| Chemical process | Martensitic S.S. | Lip seal | Bi-directional |
| Silicone | Packing | Surface treatment | |
| Glue | Drives | ||
| ATEX |
| SI | PAE | PLE | |
| Viscosity | Cp | 1-1,000,000 | 1-1,000,000 |
| Capacity range | cc/rev | 1-2,500 | 1-2,500 |
| Rotational speed | rpm | 10-80 | 10-120 |
| Max outlet pressure | psi bar |
7.250 <500 |
4,350 <300 |
| Operating temperature | °C | <350 | <120 |
