Prouduct
~13L/min
FlowMaster
튜빙펌프(Flow master)
Precision Pump > Peristaltic Pump > ~13L/min
- 제품설명
-
- 37-13,000 ml/min
- 3 convex stainless steel rollers
- 강한 내구성
- Protection rate : IP65
- 멸균상태에서 튜브 장착 가능
- Maker : Masterflex / USA
- 연락처
-
031-790-1907 (내선2)
대전지사 : 042-824-5167
- Operating Panel
- 5-button membrane key-pad
- LED display
- Operating Modes
- RUN / STOP
- Pumping by drive speed (rpm or % of max. speed)
- Speed setting, adjustable in steps of 0.1 rpm or percent of max. speed
- Pumping by time
- Rotation direction
- Settings Menu for basic settings
- Interfaces
- Analog Input : Speed control (05 or 010V / 020 or 420mA)
- Analog Output : Speed monitoring (05 or 010VDC)
- Digial Input : Start/Stop, rotation direction (5, 12 or 24V)
- Digital Outputs : relays) Status outputs (error / ok, busy)
- Voltage Output : 24VDC; 0.5A (auxiliary voltage for peripherals)
