- Differential Pressure : 5.2 max Bar
- Flow Rate : 0.85 min 3200 max ml/min
- Speed : 50 min 5000 max rpm
- Operating Panel
- 6-butten membrane key-pad
- LED display
- Operating Modes
- Pumping by drive speed (rpm)
- Pumping by flow rate (ml/min)
- Dispensing by volume (ml)
- Dispensing by time (0.1s up to 999hrs)
- Dispensing by volume within a pre-set time
- Interval dispensing by volume with a pause
- Interval dispensing by time with a pause
- Setting the number of dispensing cycles
- Pause time setting (from 0.1s up to 999hrs)
- Back-steps for drip-free dispensing
- Reversible rotation direction (only with Cavity Style pump heads)
- Calibrating Functions
- For flow rate (ml/min)
- For volume (ml)
- Interfaces
- RS232 "in" : for operation controlling via PC
- RS232 "out" : for cascading up to 8 pumps
- Analog Output : Speed monitoring (0-12 kHz)
- Digital Input Run/Stop, autostart
