기어펌프 이글 드라이브 Pump Module > Gear Pump > Pump Drive- 제품설명
-
- 높은 Torque와 Power,Higher flow rates(Maxium 8,000 rpm)
- Electromagnetic
- IP55 Package Rating
- EL/MS Drives
- Wide Range of Power Supply Voltages
- Maker : MICROPUMP / USA
- 연락처
-
경기본사 : 031-790-1907 (내선2)
대전지사 : 042-824-5167
- Increase torque and power for higjer flow rates
- Newest surface mounted electronics technology
- All moving parts eliminated to increase motor life
- Wide Range of Power Supply Voltages
- IP55 Package Rating
"
Performance Summary
| Drive Type | Electromagnetic |
|---|---|
| Speed (min) | 250 RPM |
| Speed (max) | 10,000 RPM |
| Power Source | 10 to 38 VDC |
| Mount | LE, SE - Mount |
| Speed Control | 0-5V |
| Connection | Wire Leads |
| Torque (max) | 10 oz-in |
| Nominal Watts | 48 W |
| Weight | 0.6 lbs |
