Flow rate range : 0.3-6000ml/min |
Speed range : 0.1-600rpm |
Speed resolution : 0.100rpm, 0.1rpm; 100-600rpm, 1rpm |
Flow rate accuracy : <±0.5% |
Outlet pressure : 0.3Mpa |
Motor type : Servo motor |
Display : 3 digital LED |
Control method : Mechanical keypad |
Keypad lifetime : 300,000 times |
Speed control : Rotary encoded swithch |
External speed control signal : 0-5V(standard), 0-10V, 4-20mA(optional) |
Start/stop, direction signal : Passive switch signal, such as foot pedal, Active switch signal: 24V default |
Communication interface : RS232(standard), Shenchen-N232 Communication protocol; RS485(optional), Modbus protocol(RTU mode) |
Power supply : AC 220V±10% 50Hz/60Hz (standard), AC 110V±10% 50Hz/60Hz (optional) |
Drive dimension(l*w*h) : 292*192*274(mm) |
Drive weight : 7.85kg |
Power consumption : <300W |
Condition temperature : 0-40℃ |
Relative humidity : <80% |
IP rate : IP31 |
|
