Inline Manifold Solenoid Valves

인라인 메니폴드 솔레노이드밸브 Valve > Valve Module > Solenoid valve
제품설명
  • Manifold 형태의 Isolation valves
  • 3, 4, 5, 6 Valves
  • Maker : Neptune Resarch / USA
연락처
경기본사 : 031-790-1907 (내선2)
대전지사 : 042-824-5167

Inline 3 x 2-way Normally Closed
  Specifications Materials
Part Number VDC PSIG Orifice Porting Body Poppet etc
161T111 12vdc 30 0.040 [1.0mm] 1/4 - 28 PTFE PTFE
161T112 24vdc 30 0.040 [1.0mm] 1/4 - 28 PTFE PTFE
Inline 4 x 2-way Normally Closed
  Specifications Materials
Part Number VDC PSIG Orifice Porting Body Poppet etc
161K081 12vdc 30 0.040 [1.0mm] 1/4 - 28 PCTFE PCTFE
161T080 6vdc 30 0.040 [1.0mm] 1/4 - 28 PTFE PTFE
161T081 12vdc 30 0.040 [1.0mm] 1/4 - 28 PTFE PTFE
161T082 24vdc 30 0.040 [1.0mm] 1/4 - 28 PTFE PTFE
161PP081 12vdc 30 0.040 [1.0mm] 1/4 - 28 PPS PTFE
161PP082 24vdc 30 0.040 [1.0mm] 1/4 - 28 PPS PTFE
225T081 12vdc 30 0.062 [1.5mm] 1/4 - 28 PTFE PTFE
225T082 24vdc 30 0.062 [1.5mm] 1/4 - 28 PTFE PTFE
360T081 12vdc 30 0.095 [2.0mm] 1/4 - 28 PTFE PTFE
360T082 24vdc 30 0.095 [2.0mm] 1/4 - 28 PTFE PTFE
Inline 5 x 2-way Normally Closed
  Specifications Materials
Part Number VDC PSIG Orifice Porting Body Poppet etc
161T101 12vdc 30 0.040 [1.0mm] 1/4 - 28 PTFE PTFE
161T102 24vdc 30 0.040 [1.0mm] 1/4 - 28 PTFE PTFE
LJ601301 24vdc 30 0.040 [1.0mm] 1/4 - 28 PTFE PTFE
Inline 5 x 2-way Normally Open
  Specifications Materials
Part Number VDC PSIG Orifice Porting Body Poppet etc
161T122 24vdc 30 0.040 [1.0mm] 1/4 - 28 PTFE PTFE
LJ601300 24vdc 30 0.040 [1.0mm] 1/4 - 28 PTFE PTFE
Inline 6 x 2-way Normally Closed
  Specifications Materials
Part Number VDC PSIG Orifice Porting Body Poppet etc
HTLBT012 24vdc 30 0.062 [1.5mm] 1/4 - 28 PTFE PTFE
  • 인라인 매니 폴드 밸브는 구성된 밸브들을 별도 제어하여 흐름제어 함.
  • 모든 개별 밸브 매니 폴드는 3,4,5, 6 밸브로 구성됨.
